Original Duplex with illustrated exterior and coordinated dimensioned 2D, furnished isometric 3D floor plans for 240 sqm preliminary building envelope.
Four studio apartments over two floors, using two units per level with a shared access gallery and a common staircase. Each unit has an independent sleeping/living zone, kitchenette, bath and service space.
Modern Rental Contemporary2 LevelsConcept Design StudyNC-HP-041
NC-HP-041
4-Door Studio Apartment Building
Practical Rental Design · Nillasca Construction House Plans
NILLASCA CONSTRUCTION
Original Nillasca design imagery used as an exterior style reference. Final facade must be coordinated with this sample’s floor plan.
4 separate studio unitsPrivate T&B per unitCommon stair accessRental-focused designShared service zones
2D Floor Plans & Furnished 3D Views
Explore the dimensioned concept plans, furnished 3D floor views, room schedules, and design considerations below.
Design study, not a construction drawing. The Nillasca exterior image is a visual direction reference; the original 2D/3D plans are preliminary and require licensed professional coordination before use.
Exterior massing illustration for design discussion. Appearance, layout, and engineering require coordination for the actual site.
160 sqmTotal conceptual gross floor envelope
8 × 10 mBuilding footprint (80.0 sqm)
160 sqmIllustrative lot: 10 × 16 m
4 Units4 T&B target
PRELIMINARY DESIGN SAMPLE — NOT FOR CONSTRUCTION. The layouts and dimensions here are preliminary concept drawings, not licensed/signed plans. Actual site setbacks, legal compliance, wall thickness, usable clearances, stairs, doors, utilities, waterproofing, structural systems and permit requirements require professional verification; recommended lot area does not guarantee buildability.
Ground Floor: Architectural-Style 2D and Furnished 3D
The dimensioned plan and 3D cutaway below share the same original room partition coordinates. Ground Floor shown as a preliminary design study; room clearances, doors and fixtures must be verified before any construction document is issued.
Ground Floor 2D presentation drawing with room dimensions, wall lines, indicative doors, windows and furniture.Ground Floor furnished 3D isometric view corresponding to the 2D layout.
View Ground Floor Room Dimension Schedule
Room / zone
Nominal size
Approx. area
Shared Gallery L1
8 × 1.3 m
10.4 sqm
Common Stair L1
1.8 × 4 m
7.2 sqm
Shared Service / Passage
1.8 × 4.7 m
8.5 sqm
Studio 1: Living / Bed
3.1 × 4.4 m
13.6 sqm
Studio 1: Kitchenette
3.1 × 2 m
6.2 sqm
Studio 1: T&B
1.6 × 2.3 m
3.7 sqm
Studio 1: Service
1.5 × 2.3 m
3.4 sqm
Studio 2: Living / Bed
3.1 × 4.4 m
13.6 sqm
Studio 2: Kitchenette
3.1 × 2 m
6.2 sqm
Studio 2: T&B
1.6 × 2.3 m
3.7 sqm
Studio 2: Service
1.5 × 2.3 m
3.4 sqm
Second Floor: Architectural-Style 2D and Furnished 3D
The dimensioned plan and 3D cutaway below share the same original room partition coordinates. Second Floor shown as a preliminary design study; room clearances, doors and fixtures must be verified before any construction document is issued.
Second Floor 2D presentation drawing with room dimensions, wall lines, indicative doors, windows and furniture.Second Floor furnished 3D isometric view corresponding to the 2D layout.
View Second Floor Room Dimension Schedule
Room / zone
Nominal size
Approx. area
Shared Gallery L2
8 × 1.3 m
10.4 sqm
Common Stair L2
1.8 × 4 m
7.2 sqm
Shared Service / Passage
1.8 × 4.7 m
8.5 sqm
Studio 3: Living / Bed
3.1 × 4.4 m
13.6 sqm
Studio 3: Kitchenette
3.1 × 2 m
6.2 sqm
Studio 3: T&B
1.6 × 2.3 m
3.7 sqm
Studio 3: Service
1.5 × 2.3 m
3.4 sqm
Studio 4: Living / Bed
3.1 × 4.4 m
13.6 sqm
Studio 4: Kitchenette
3.1 × 2 m
6.2 sqm
Studio 4: T&B
1.6 × 2.3 m
3.7 sqm
Studio 4: Service
1.5 × 2.3 m
3.4 sqm
Key Features & Design Intent
Four independent studio units with own T&B
Two rental units on each floor
Common access gallery and aligned stairs
Kitchenette provided inside each unit
Clear separation of rentable and common space
Planning and Lot Requirements
The initial building envelope is 8 m wide × 10 m deep, with approximately 160 sqm combined floor plate area. The 10 × 16 m lot assumption is for early layout comparison only; a boundary survey, site orientation and applicable local zoning and building regulations must be reviewed.
Parking concept: Site parking requires independent feasibility study. Actual frontage and parking requirements must be verified separately. Window locations and door swing marks are diagrammatic; they are not final door or window schedules.
Why This Layout Works
Four studio apartments over two floors, using two units per level with a shared access gallery and a common staircase. Each unit has an independent sleeping/living zone, kitchenette, bath and service space. The planning responds to modern rental contemporary aesthetics while seeking functional circulation, efficient room proportions, daylight and ventilation appropriate for Philippine residential use.
Next Design & Build Steps
For a proposed four-studio rental building, review our apartment construction planning in Laguna. Confirm the site, intended occupancy, circulation, shared services, and approval requirements before using this concept as a starting point. Reference NC-HP-041 in your inquiry.
These preview visuals are illustrative. All structural/technical plans require authorized professional sign-off before permitting or construction.
